Trailed version - TOP 422 A and TOP 462 A offers high performance with small tractors.
For large working widths with small tractors, PÖTTINGER offers you two single-rotor rakes as trailed versions.
Key features:
- Thanks to the trailed design, no load is exerted on the tractor hitch. Easy attachment and detachment is guaranteed.
- Thanks to the parallelogram drawbar, both trailed versions can be hitched to the tractor's linkage bar or ring hitch.
- The machine is lifted hydraulically into the transport position conveniently controlled from the tractor seat. Hydraulic cylinders on the chassis and drawbar provide 50 cm of ground clearance.
- The two models offer you a working width of 4.20 m and 4.60 m.
- The tandem axles are fitted with 18.5 x 8.5-8 flotation tyres as standard. This means that your machine runs smoothly both during operation and on the road.
- 2.48 transport width
- 1.6m - 1.65m Swath width.
- 12 pieces removable tine carrier arms per rotor
- TOPTECH Plus rotor unit
- 860kg weight
- Rigid rotor wheels
- turnbuckle height adjustment system
- Tandem axle
- 16x6.5-8 rotor tyres
- Swath curtain
- Wide-angle P.T.O. shaft on one end
Optional extras:
- Hydraulic swath curtain lift system
- Tandem axles
- MULTITAST jockey wheel
